n Advanced HMI operation, PLC control;

n Capping speed is fast, precise and tight. The surface is made of 304 stainless steel.

n Hand wheel regulation; it can apply to varied bottle caps within the scope of this machine without replacement of parts by simply adjusting the synchronous belt, distance between caps and rack height

n It applies to varied plane caps of tall and short bottles which are round, square or oblate in shape.

Scope of application:

n It applies to capping of plane caps of round, square and oblate bottles for food, medicine, cosmetics and chemicals;

Item

XL-80/100

 Cap diameter

φ15-55mm

瓶体直径 Bottle diameter

φ20-55mm

 Bottle height

100-320mm

Screwing speed

60-100瓶/分bottles/min

 Power

AC220V 50/60Hz W

Weight

Pressure range

0.4-0.6Mpa

Host dimension

3300×600×1550mm(不包括提升机)

(excl. elevators)
